Product Model:
12CH synchronized A/V recording and playback（ 8CH AHD 1080P+4CH IPC）
8x 1080P AHD +4CH IPC
Support 2*4TB HDD and 1*512GB SD card
Internal G-Sensor, GPS/3G/4G/5G/WIFI Optional
Support 1*USB ( Mouse operation)
On board UPS 8 seconds delay power-off for data protection
8V-36V wide voltage power supply
OS | Linux | |
User interface | Support E-set, remote controller, remotely operation, SD card, etc to configure | |
Language | English, Chinese (option customized) | |
Security | User password, Administrator password management | |
Video & preview | Input/output | 8ch 1080P AHD input and 4CH IPC Input, aviation Plug, 1.0Vp-p, 75Ω
|
OSD | Overlays letters… like date /time, vehicle ID | |
Compression | H.265 | |
Dual stream | Record with HD video and remotely live view with lower stream | |
preview | 1 channel/Quad preview; support events trigged to full screen and video switch | |
Speed(frame rate) | PAL: 100fps, each channel 25fps; NTSC: 120fps, each channel 30fps | |
Resolution | 1080P/960P/720P /D1 optional | |
Image quality | 1-6 Level optional | |
Video rate | CIF: 256Kbps ~ 1.5Mbps, multi levels video quality optional; HD1: 600Kbps ~ 2.5Mbps, multi levels video quality optional; D1: 800Kbps ~ 3Mbps, multi levels video quality optional; 720P : 1Mbps~4Mbps, multi levels video quality optional; 1080P: 1Mbps~8Mbps, multi levels video quality optional; | |
Audio | Audio input/output | 12 channel Aviation, 1channel VGA,1 channel HDMI, 1 channel aviation output. |
Compression | G726 | |
Record | Storage | 2.5’’ HDD+ SD Card ,each max 4TB HDD + 512GB SD Card*2 |
USB | Front panel supports USB port, support USB flash disk upgrade to backup; hard disk box USB port, can back up video data | |
File System | Special Car system File System | |
Record strategy | Default power-on record, also support time schedule record, alarm record and events trigger record | |
Upgrade | Support USB flash disk updating SD card upgrade , OTA remote upgrade automatically | |
Alarm | Input | 8 channel level signal, support alarm linkage |
Output | 2 channel level signal output | |
Communication | Serial Port | Support 4 channel RS232 and connect extension device, such as POS machine, Oil Fuel sensor, LED advertising screen and Support 4 channel RS485 can connect PTZ,
|
3G/4G/5G/WIFI | Support 3G/4G/5G and compatible with GPRS, EDGE; built-in WIFI | |
G-Sensor | Built-in G-Sensor | |
GPS(option) | Support GPS, BD/GLONASS optional | |
Firmware upgrading | SD card; remotely upgrade; USB pen driver upgrade | |
Power supply & consumption | Power manage | ACC on/off; delay off; |
Voltage | DC:+9V ~ +36V | |
Voltage output | +12V@2.5A : +5V@1A | |
Power failure protection | Built-in UPS, to ensure the record completely when power failure suddenly | |
Consumption | Normal Working: <14W; Standby: <0.5W Support turning off with no power consumption | |
Work Environment | Temperature | -20℃ ~ +80℃ |
Humidity | 10% ~ 95% | |
Size | 167(W) x 170(H) x 231(L) mm | |
Weight | Net weight:4KG; Gross weight: 4.5KG | |
